138-960MHz N female 3dB Hybrid coupler Public Safety Communication Critical Communication Distributed Antenna System 138-960MHz N female 3dB Hybrid coupler Public Safety Communication Critical Communication Distributed Antenna System
138-960MHz N female 3dB Hybrid coupler Public Safety Communication Critical Communication Distributed Antenna System 138-960MHz N female 3dB Hybrid coupler Public Safety Communication Critical Communication Distributed Antenna System
138-960MHz N female 3dB Hybrid coupler Public Safety Communication Critical Communication Distributed Antenna System 138-960MHz N female 3dB Hybrid coupler Public Safety Communication Critical Communication Distributed Antenna System

138-960MHz N female 3dB Hybrid coupler Public Safety Communication Critical Communication Distributed Antenna System

5 0 Reviews

Availability:
Quantity:
  • VN-HC2x2-138960-ONx-xxx.doc

  • Vinncom or OEM brand

138-960MHz air dielectric 3dB hybrid coupler is made with good PIM value with vinncom stable design ,VSWR can be 1.20:1 typically ,and PIM can be -165dBC at 43dBm*2 ,we can test different band with Rosenberger passive intermodulation testers,it is widely used in critical and public safety communication
Product Description

Features:

1.Strip-line and air-dielectric design

2.Frequency 138-960MHz

3.Distributed Antenna System (DAS)

4.In-building wireless signal coverage solution


138-960MHz 3dB coupler designed for public safety and critical communication  is made with good PIM value with vinncom stable design ,VSWR can be 1.20:1 typically ,and PIM can be -165dBC at 43dBm*2 ,we can test different band with Rosenberger passive intermodulation testers,it is widely used in critical and public safety communication

1

VN-HC2x2-138960-ON-xxx.pdf

138-960MHz N Female Air Dielectric 3dB Hybrid Coupler


Part Number

VN-HC2x2-138960-ON-xxx

Operating Frequency ( MHz )

138-960

Impedance ( Ohm )

50

VSWR

1.3

Coupling (dB)

3

Insertion Loss (dB)

+/-1.0

Isolation (dB)

21

IM3 (dBc @ 2*43dBm)@

-150/-153/-163/-165

Application

Indoor & Outdoor

Degree of Protection

IP65

Operating Temperature ( ℃ )

-40 ~ + 80

Interface

N Female

Handling Power (Watt, max)

300

Peak Power (Watt, max)

1200

Dimension (mm)(L*W*H, excl connector)

201*98*39

Net Weight (g)

1515g +/-5%

Packing Dimensions (mm,L*W*H)

210*170*65

Packing Carton Size (mm,L*W*H)

530*440*80

ROHS Compliance

Yes

Revision

R1

Date

12-October -2020
