Features：
1.Reactive Power Splitter Design
2.High Power handling 500watts
3.Low PIM Optional,-150dBC~-165dBC@43dBm*2
4.Good Flatness with round outline design
5.DIN Female Design
VN-PS-0727-OD3-R-xxx.pdf VN-PS-0738-OD3-R-xxx.pdf
VN-PS-0740-OD3-R-xxx.pdf VN-PS-0742-OD3-R-xxx.pdf
698-2700/3800/4000/4200MHz 3 Way DIN Female Reactive Power Splitter
Part Number | VN-PS-07xx-OD3-R-xxx |
Operating Frequency ( MHz ) | 698-2700 698-3800 698-4000 698-4200 |
Impedance ( Ohm ) | 50 |
VSWR | ≤1.30 |
Split Loss (dB) | ≤5.3 |
IM3 (dBc @ 2*43dBm)@xxx | -150 / -155 / -160/-165 |
Application | Indoor & Outdoor |
Degree of Protection | IP65 |
Operating Temperature ( ℃ ) | -40 ~ + 80 |
Interface | Din Female |
Handling Power (Watt, max) | 500 |
Peak Power (Watt, max) | 1500 |
Dimension (mm)(L*W*H, excl connector) | 260*25*25 |
Net Weight (g) | 320g+/- 20 |
Packing Dimensions (mm,L*W*H) | 280*80 *50 |
Packing Carton Size (mm,L*W*H) | 580*420*160 |
ROHS Compliance | Yes |
Revision | R1 |
Date | 27-Sept -2020 |
