20 DB Directivity Dual Band Two Way Radio for Customized Communication Requirements

Product Description:

The RF Hybrid Coupler is a versatile and high-performance component designed for use in various applications where signal splitting and combining are required. This product offers exceptional performance in terms of insertion loss, temperature range, frequency range, coupling, and PIM levels.

Insertion Loss: The RF Hybrid Coupler features an insertion loss of 0.2 dB, ensuring minimal signal loss during signal splitting and combining processes. This low insertion loss is crucial in maintaining signal integrity and efficiency.

Temperature Range: With a wide temperature range of -55°C to +85°C, this RF Hybrid Coupler is suitable for use in diverse environmental conditions. It can withstand extreme temperatures, making it ideal for both indoor and outdoor applications.

Frequency Range: The RF Hybrid Coupler offers a broad frequency range of DC to 18 GHz, allowing it to support a wide range of RF signals. This wide frequency coverage makes it a versatile component for various RF systems and applications.

Coupling: This RF Hybrid Coupler provides a coupling factor of 3 dB, enabling efficient signal splitting and combining operations. The 3 dB coupling ensures that signals are evenly distributed across multiple output ports with minimal loss.

PIM: The RF Hybrid Coupler features excellent PIM (Passive Intermodulation) performance with PIM levels of 153 dbc and 163 dbc at 43 dBm*2. This high PIM rating ensures that the RF signals remain clean and undistorted, even at high power levels, resulting in superior signal quality.

The RF Hybrid Coupler is a reliable and durable component that is suitable for a wide range of applications, including but not limited to:

• Between Series RF Adapter: The RF Hybrid Coupler can be used as a signal splitter or combiner in between series RF adapter setups, enabling seamless connectivity and signal distribution between different RF devices.
• Between Series RF Adapter: Its high-performance characteristics make it an ideal choice for applications that require precise signal handling and distribution, such as in between series RF adapter configurations.
• Dual Band Two Way Radio: The RF Hybrid Coupler is well-suited for dual-band two-way radio systems, providing efficient signal splitting and combining capabilities for enhanced communication performance.

Overall, the RF Hybrid Coupler is a reliable, high-quality component that offers exceptional performance in terms of insertion loss, temperature range, frequency range, coupling, and PIM levels. Its versatility and durability make it an ideal choice for various RF applications where signal splitting and combining are essential.

Features:

• Product Name: RF Hybrid Coupler
• Frequency Range: DC-18 GHz
• Temperature Range: -55°C To +85°C
• Isolation: 20 DB
• Color: Customized
• Low Vswr: 1.30

Technical Parameters:

Applications:

Vinncom's RF Hybrid Coupler model VN-HC2x2-15001-ON-xxx is a versatile and high-quality product suitable for a variety of applications across different industries. With its origins in China and certifications in ROHS and ISO9000, this hybrid coupler guarantees both reliability and performance.

One of the key attributes of this product is its exceptional directivity of 20 dB, ensuring precise signal control and management. The connector type of SMA further enhances its compatibility and ease of integration into existing systems. Additionally, the insertion loss of only 0.2 dB and isolation of 20 dB make it an efficient and effective component for signal distribution and splitting.

Designed with low VSWR of 1.30, the VN-HC2x2-15001-ON-xxx hybrid coupler is ideal for applications that require minimal signal reflection and maximum power transfer. Its high-quality construction and performance make it a reliable choice for various scenarios.

Product Application Occasions and Scenarios:

- Between Series RF Adapter: The RF hybrid coupler can be used in between series RF adapters to combine or split signals efficiently. Its low VSWR and high isolation make it ideal for maintaining signal integrity in RF systems.

- DMR Two Way Radio: The VN-HC2x2-15001-ON-xxx hybrid coupler is suitable for DMR two-way radio systems, providing reliable signal splitting and distribution for seamless communication.

- Dual Band Two Way Radio: For dual-band two-way radio applications, this hybrid coupler can effectively manage and distribute signals across different frequency bands, ensuring optimal performance and signal quality.

Customization:

Enhance your Coaxial RF Directional Coupler with our Product Customization Services, exclusively from Vinncom. Our model number VN-HC2x2-15001-ON-xxx ensures top-notch performance, originating from China with certifications in ROHS and ISO9000 standards.

Customize the color to suit your preferences while enjoying 20 DB Isolation, ±0.2 DB Amplitude Balance, 3 DB Coupling, and 20 DB Directivity. Elevate your experience with this Dual Band Two Way Radio essential.
