ISO9000 2in 1out 3dB Signal RF Antenna Combiner 550-6000MHz

Hot Products

Test Cable And Jumper

sales@vinncom.com

+8617755151077

Contact Now

ISO9000 2in 1out 3dB Signal RF Antenna Combiner 550-6000MHz

MOQ:	5 pcs
Price:	Negotiable
Payment Method:	D/A, L/C, D/P, T/T
Supply Capacity:	300pcs per day

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

Vinncom

Certification

ROHS ISO9000

Model Number

VN-LPHC2x1-05560-OP

Frequency:

550-6000MHz 600-6000MHz

Connector:

4.3-10 Female

Color:

Customized

OEM/ODM:

Acceptable

Low PIM:

-153dbc -163dbc

Application:

DAS IBS Public Safety

ROHS:

Compliance

Design:

Wide Band

Highlight:

2in 1out RF Antenna Combiner

3dB RF Antenna Combiner

ISO9000 antenna signal combiner

Product Description

550-6000MHz 600-6000MHz 4.3-10 Mini Din Female -153dbc -163dbc Low PIM 2IN 1OUT Hybrid Combiner

Wide band
High isolation
Good PIM up to -160@43dBm*2

Part Number	VN-LPHC2x1-05560-OP
Operating Frequency ( MHz )	550-6000
Impedance ( Ohm )	50
VSWR	1.40
Coupling (dB)	3
Insertion Loss (dB)	≤1.5(splitting loss not including)
Isolation (dB)	23
IM3 (dBc @ 2×43dBm)	-160
Application	Indoor & Outdoor
Degree of Protection	IP65
Operating Temperature ( ℃ )	-40 ~ + 80
Interface	4.3-10 Female
Handling Power (Watt, max)	100
Peak Power (Watt, max)	1000
Dimension (mm)(L×W×H, excl connector)	220X170X68
ROHS Compliance	Yes

The hybrid combiner is used to split and combiner RF signals. It is related to the 3 dB hybrid which is based on PCB transmission lines or dielectric 3db hybrid , and is most commonly used as combiner in distributed antenna system(DAS).

Vinncom has many types of hybrid combiner for different frequency ,from 130MHZ to 6000MHZ ,for example ,2in1out ,

3in 3out ,and 4in 4out for different usage and customized products also welcomed .
