4.3-10 Inline Low PIM Attenuator Weatherproof 617-2700MHz
  • name
  • name
  • name
  • name

4.3-10 Inline Low PIM Attenuator Weatherproof 617-2700MHz

MOQ: 10
Price: Negotiable
Payment Method: L/C, D/A, D/P, T/T, T/T
Supply Capacity: 100pcs per day
Detail Information
Product Description
Detail Information
Place of Origin
CHINA
Brand Name
Vinncom
Certification
ROHS ISO9000
Model Number
VN-LPAT-0727-50W-OPx
Connector:
4.3-10 Male-4.3-10 Female
Frequency:
698-2700 MHz ,617-2700MHz
Design:
Coupler+Cable Rolling
PIM:
-165dbc @ 43dbm*2
Color:
Black Or Customized
Highlight:

Inline Low PIM Attenuator

,

Weatherproof Low PIM Attenuator

,

4.3-10 Inline Attenuator

Product Description

698-2700MHz 50W 4.3-10 Male To 4.3-10 Female Low PIM -155dbc 160dbc  5~40dB RF Coaxial Attenuators



  • Wide band frequency
  • Low PIM up to -155/-163dBc@43dBm*2
  • High attenuation accuracy



Part Number VN-LPAT-0727-50W-OPx
   Operating Frequency ( MHz )    698-2700
Impedance ( Ohm ) 50
VSWR ≤1.25
Attenuation (dB) 5 ± 0.8 6 ± 0.8 7 ± 0.8 10 ± 0.8 15 ± 1 20 ± 1 30 ± 1.2 40 ± 1.5
IM3 (dBc @ 2×43dBm) -155 / -163
Application Indoor & Outdoor
Degree of Protection IP65
Operating Temperature ( ℃ ) -40 ~ + 80
Interface 4.3-10 Male to 4.3-10 Female
Handling Power (Watt, max) 50
Peak Power (Watt, max) 500
Dimension (mm) 220 × 170 × 68 (excludes connector)
ROHS Compliance Yes









4.3-10 Inline Low PIM Attenuator Weatherproof 617-2700MHz 0



RF attenuators usually can be used to reduce the power of the signal within many RF circuit designs and RF systems. These RF attenuators can be fixed, switched,surface mounted or even continuously variable.

Vinncom has many types of RF attenuators with different frequency range. Vinncom also can supply attenuators with good PIM value(-160 dbc@43dbm*2) in some RF syetems.



Tags:

high power rf attenuator,

wideband attenuator,

rf step attenuator
