340/380-2700MHz 2 Way N Female Power Splitter

Name: 340/380-2700MHz 2 Way N Female Power Splitter
Brand: HeFei Vinncom Electronic Technology Co.,Ltd.
SKU: VN-PS-03427-ON2
Price: 414.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Vinncom

Certification: ISO 9000 ROHS

Model Number: VN-PS-03427-ON2

Payment & Shipping Terms

Minimum Order Quantity: 5 pcs

Price: negotiable

Payment Terms: L/C, D/A, D/P, T/T

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                      340MHz Power Splitter, 2700MHz Power Splitter, IP65 Power Splitter


Connector:	N Female	Frequency Range:	340-2700MHz
Impedance:	50 Ohm	Insertion Loss:	3.3 DB
Power Rating:	1500W	Product Name:	Splitter
RoHS Compliant:	Yes	Size:	318 × 25 × 25mm
Temperature Range:	-55 To +85°C	VSWR:	1.25:1

Connector:	N Female
Frequency Range:	340-2700MHz
Impedance:	50 Ohm
Insertion Loss:	3.3 DB
Power Rating:	1500W
Product Name:	Splitter
RoHS Compliant:	Yes
Size:	318 × 25 × 25mm
Temperature Range:	-55 To +85°C
VSWR:	1.25:1

Description

340/380-2700MHz 2 Way N Female Power Splitter

340-2700MHz 2 Way Power Splitter

Good VSWR
Low PIM up to -161dBc@43dBm*2
Wide band frequency

VN-PS-03427-ON2-xxx.pdf

Part Number	VN-PS-03427-ON2
Operating Frequency ( MHz )	340-2700
Impedance ( Ohm )	50
VSWR	≤1.25
Split Loss (dB)	≤3.3
IM3 (dBc @ 2×43dBm)	-161
Application	Indoor & Outdoor
Degree of Protection	IP65
Operating Temperature ( ℃ )	-40 ~ + 80
Interface	N Female
Handling Power (Watt, max)	500
Peak Power (Watt, max)	1500
Dimension (mm)(L×W×H, excl connector)	318 × 25 × 25
Net Weight (g)	610 ± 20
Packing Dimensions (mm,L×W×H)	420×80×40
Packing Carton Size (mm,L×W×H)	434×435×195
ROHS Compliance	Yes
