Name: Adapter N female To NEX-10 female
Brand: HeFei Vinncom Electronic Technology Co.,Ltd.
SKU: VN-ADR-NF-NEX10F
Price: 414.00 USD
Availability: InStock

MOQ:	5pcs
Price:	negotiation
Standard Packaging:	foam+box
Delivery Period:	depends on your quantity
Payment Method:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Capacity:	50pcs per day

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

Vinncom

Certification

RoHS/ISO9000

Model Number

VN-ADR-NF-NEX10F

Frequency Range:

DC-3GHz

Characteristic Impedance:

Insertion Loss:

≤0.05

Dielectric Resistance:

≥5000MΩ

Temperature Range:

-40℃～+85℃

VSWR:

≤1.10

Dielectric Withstanding Voltage:

≥750V RMS,50Hz,at Sea Level

PIM ( @2-tonex20w):

≤-155dBc

Highlight:

NEX-10 female Adapter

N female Adapter

Product Description

Adapter N female To NEX-10 female

Good VSWR
Wide band frequency
Low PIM

SPECIFICATION
Dimensions are in millimeters
Interface
According to			IEC 60169-16(N)
Electrical
Characteristic Impedance			50 ohm
Frequency Range			DC-3GHz
VSWR			≤1.10
PIM ( @2-tonex20w)			≤-155dBC
Insertion Loss			≤0.05*√fdB
Dielectric Withstanding Voltage			≥750V RMS,50Hz,at sea level
Dielectric Resistance			≥5000MΩ
Contact Resistance			Center Contact ≤2.5mΩ
			Outer Contact ≤3.0mΩ
Mechanical
Durability			Mating cycles ≥100 cycles
Material and plating
	Material			plating
Body	Brass			Tri-Alloy
Insulator	PTFE			-
Center conductor	Phosphor bronze			Ag
Environmental
Temperature Range		-40℃～+85℃
Rosh-compliance		Full ROHS compliance
Salt-fog test		96h

Adapter N female To NEX-10 female 0
