37-40.5GHz COAXIAL FILTER

Hot Products

Waveguide Devices

sales@vinncom.com

+86 177 5515 1077

Contact Now

37-40.5GHz COAXIAL FILTER

MOQ:	5 pcs
Price:	negotiable
Payment Method:	L/C, D/A, D/P, T/T
Supply Capacity:	500

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

Vinncom

Certification

ISO 9000 ROHS

Model Number

VN-CFLT-KM-3740

Part Number:

VN-WGLD-75110-WR10

Operating Frequency ( GHz ):

37-40.5

Impedance ( Ohm ):

Insertion Loss(dB):

Return Loss(dB):

RF Connectors:

2.92mm-Male&2.92mm-Female

Highlight:

37-40.5GHz coaxial filter

waveguide coaxial filter

microwave coaxial filter

Product Description

374-40.5GHz COAXIAL FILTER

High power handling capability (both average and peak)
Low insertion loss in the passband
Multiple filter types available (band‑pass, low‑pass, high‑pass, band‑stop)

Working Principle of a WAVEGUIDE FILTER

A WAVEGUIDE FILTER is a passive frequency‑selective waveguide component.
A WAVEGUIDE FILTER allows signals within a specific frequency band to pass with very low insertion loss.
Outside that passband, a WAVEGUIDE FILTER provides high attenuation (rejection) to unwanted signals.
A WAVEGUIDE FILTER operates based on resonant cavities, irises, or coupled sections within the waveguide structure.
A WAVEGUIDE FILTER can be designed as a low‑pass, high‑pass, band‑pass, or band‑stop (notch) type.
A WAVEGUIDE FILTER uses the physical dimensions of its cavities to determine the resonant frequency.
When a signal matches the resonant frequency of a WAVEGUIDE FILTER, it passes through with minimal reflection.
When a signal is off‑resonance, a WAVEGUIDE FILTER reflects or absorbs it, preventing transmission.
A WAVEGUIDE FILTER achieves its filtering function without any external power or active components.

VN-CFLT-KM-3740.pdf

Part Number	VN-CFLT-KM-3740
Operating Frequency ( GHz )	37-40.5
Rejection(dB)	45dB@29GHz-35.25GHz/40dB@42GHz-48GHz
Insertion Loss(dB)	≤2.0
Return Loss(dB)	≥14
RF Connectors	2.92mm-Male&2.92mm-Female
Operating Temperature ( ℃ )	0 ~ + 55
Dimension(mm)	As below
ROHS Compliance	Yes

37-40.5GHz COAXIAL FILTER
