DC-16.5 GHz COAXIAL FILTER
  • name

DC-16.5 GHz COAXIAL FILTER

MOQ: 5 pcs
Price: negotiable
Payment Method: L/C, D/A, D/P, T/T
Supply Capacity: 500
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
Vinncom
Certification
ISO 9000 ROHS
Model Number
VN-CFLT-SF-DC16
Part Number:
VN-CFLT-SF-DC16
Operating Frequency ( GHz ):
DC-16.5
Impedance ( Ohm ):
50
Insertion Loss(dB):
≤0.5
Return Loss(dB):
16
RF Connectors:
SMA-M&SMA-F
Highlight:

DC-16.5 GHz coaxial filter

,

Waveguide coaxial filter

,

High-frequency coaxial filter

Product Description

DC-16.5GHz COAXIAL FILTER



  • Protects downstream components from out‑of‑band energy
  • Improves system signal‑to‑noise ratio (SNR)
  • High reliability in harsh environments (vibration, temperature, humidity)





Application Scenarios / Working Scenarios of a WAVEGUIDE FILTER

  • Radar systems –
    A WAVEGUIDE FILTER separates transmit and receive frequencies in a frequency‑agile radar, or rejects out‑of‑band interference.

  • Satellite communication (Satcom) ground stations –
    A WAVEGUIDE FILTER removes unwanted spurious emissions from the upconverter before the signal reaches the antenna.

  • Electronic warfare (EW) systems –
    A WAVEGUIDE FILTER selects the desired frequency band while rejecting jamming signals outside that band.

  • Test and measurement setups –
    A WAVEGUIDE FILTER is used in network analyzer calibration to create clean, harmonic‑free test signals.

  • Microwave transmitters and amplifiers –
    A WAVEGUIDE FILTER suppresses harmonics and out‑of‑band products generated by nonlinear amplifier stages.

                                  VN-CFLT-SF-DC16.pdf

Part Number VN-CFLT-SF-DC16
Operating Frequency ( GHz ) DC-16.5
Rejection(dB) 32dB@26.5GHz-40GHz
Insertion Loss(dB) ≤0.5
Return Loss(dB) 16
RF Connectors SMA-M&SMA-F
Operating Temperature ( ℃ ) -40 ~ + 85
Dimension(mm) As below
ROHS Compliance Yes







DC-16.5 GHz COAXIAL FILTER
